In the Kreo project, it is possible to apply runtime filters to the data stored in various data structures, allowing the creation of a report based on a subset of the recorded data.
The available filters for report generation are:
Time range filter: The user specifies a start and end date-time (format: YY-MM-DD-hh-mm-ss)
Batch ID filter: Filters data based on the production batch identifierKeyword + time range filter:
Filters data based on a keyword within a specified time range
Data structure
The following data structures can be included in the report:
Datalog: Can be displayed in the report either as a table or as a trend view
UserLog: User login/logout log, displayed in tabular form
HistoryAlarm: Alarm history, displayed in tabular form
EventsLog: Event log that records all operations performed by the operator. The definition of which events are logged is configured in the FDA function
Recipes: Recipe archive, displayed in tabular form
